Section 12 - SeVG Plus
Actuator
WARNING
Ensure that you have fully read “Section 3 - Safety” before assembling or
installing the SeVG Plus actuator.
The actuator operates with life threatening voltages and imposes a risk
of personnel exposure to dangerous situations such as electrical shock.
Personnel performing operation, maintenance, mounting or any other
activities with the actuator should be correspondingly trained in safe
operation of the actuator and prevention of dangerous situations.
All activities should only be performed by qualied specialists who have
professional training in installation and operation of a linear servo actuator.
WARNING
-
HIGH VOLTAGE
The motor rod is not considered a reliable ground connection.
12.1 Introduction
The SeVG Plus is an industrial grade actuator intended to perform the
functions of moving the working mechanisms and providing the necessary
force and speed for a given control cycle when installed in a Hot Runner
system.
12.2 SeVG Plus Actuator Models
The SeVG Plus actuator is available in three models:
Table 12-1 SEVG Plus Actuator Models
Model Closing Force Stroke Cooled
SE20-15 2.0 kN 15 No
SE40-20 4.0 kN 20 No
SE40-20C 4.0 kN 20 Yes
The size and options for the SeVG Plus actuator depend on the system
requirements. Please check your General Assembly drawings to conrm the
type of SeVG Plus actuator in your system.
12.3 SeVG Plus Actuator in Hot Runner Systems
The Master-Series Hot Runner system has the exibility to use all three
models of SeVG Plus actuator, depending on the type of system.
See Table 12-2.
Table 12-2 Hot Runner Systems: SeVG Plus Actuator Selection
System Type SE40-20C SE40-20 SE20-15
Plate Mounted
x x x
12-1SEVG PLUS ACTUATOR
Hot Runner User Manual
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
