4. Install the bottom spring.

NOTE

The bottom spring has a di󰀨erent orientation from that of other

MasterSHIELD systems.

5. Install the top spring.

NOTE

The top spring has a di󰀨erent orientation to that of the bottom spring.

5-20

ASSEMBLY

Hot Runner User Manual
