Extraction of 2-piece Valve Disk - continued
4. Attach EXTOOLAS10 to the extraction tool for the valve disk stem.
NOTE
For close pitch conditions, use EXTOOLAS10 with a spacer.
5. Extract the valve disk from the manifold.
IMPORTANT
Ensure that the pulling direction is perpendicular to the manifold surface.
15-5MAINTENANCE
Hot Runner User Manual
