7. Feed the wires back through the wire channel in the mold base to the
electrical box.
8. For electrical checks, refer to “Section 6 - Electrical Testing”.
1. Inlet extension
2. Manifold
3. Extension tip
4. Pressure sleeve
1
2
3
4
Figure 5-43 Inlet extension with sleeve
Inlet Extension with Pressure Sleeve - continued
