NEC DSX Software Manual

Caller ID Logging
72 ◆ Features DSX Software Manual
Programming Examples
1. In 3121-01: Caller ID Type (page 825) for each line enter the type of Caller ID required:
- (DSP = 1, ATRU-DB = 2, T1/E1 ANI = 3).
2. Set up the outbound route for Caller ID callbacks.
- In 3711-01: Caller ID Callback Route Type (page 856), select the type of route used for Caller ID
callbacks (1 = line, 2 = Line Group).
- For line, in 3711-01: Caller ID Callback Line (page 856) enter the line number (1-64) the system
will use for Caller ID callbacks.
- For Line Groups, in 3711-01: Caller ID Callback Group (page 857) enter the Line Group number
(90-98) the system will use for Caller ID callbacks.
3. In 3712-02: 10-Digit Local Calls (page 858), enter No.
4. In 3713-[01-16]: Home Area Code Table Data (page 860),enter 203.
- The system will add a leading 1 to all calls to all area codes other than 203.
- Calls to area code 203 will be redialed as 7-digit calls.
1. In 3121-01: Caller ID Type (page 825) for each line enter the type of Caller ID required:
- DSP = 1
- ATRU-DB = 2
- T1/E1 ANI = 3).
2. Set up the outbound route for Caller ID callbacks.
- In 3711-01: Caller ID Callback Route Type (page 856), select the type of route used for Caller ID
callbacks (1 = line, 2 = Line Group).
- For line, in 3711-01: Caller ID Callback Line (page 856) enter the line number (1-64) the system
will use for Caller ID callbacks.
- For Line Groups, in 3711-01: Caller ID Callback Group (page 857) enter the Line Group number
(90-98) the system will use for Caller ID callbacks.
3. In 3712-02: 10-Digit Local Calls (page 858), enter Yes.
4. In 3713-[01-16]: Home Area Code Table Data (page 860),enter 203.
5. In 3714-[01-96]: Home Area Code Exception List Table Data (page 861):
- Configure the table as a local table (L).
- Enter the local exchanges within area code 203.
- Calls within area code 203 that are found in the list are redialed as 10-digit local calls. Calls within
area code 203 not found in the list are redialed as 1 + 10 digit toll calls.
6. In 3715-[01-96]: Foreign Area Code Exception List Table Data (page 862), enter the NPA + NXX com-
bination for area code 860 that is a local call. The call is redialed as a 10-digit local call.
Other Related Features
Features
Caller ID (page 63)
Caller ID automatically displays the phone number and optional name for incoming outside calls.
IntraMail Features
None
1.
Enable Caller ID callbacks (return calls) for a system in area code 203.
• There is no 10-digit local calling or other special requirement.
2.
Enable Caller ID callbacks (return calls) for a system in area code 203 where there is 10-digit
local calling and a local exchange in adjacent area code 860.
