8 ◆ Introduction DSX Software Manual
Analog Door Boxes, Built-In 20
Analog Door Boxes, Total The maximum number of DSX Analog Door Boxes you can install is determined by
the number of 2PGDAD Modules, which in turn is limited only by the availability
of 16ESIU station ports.
DSS Consoles 4
The System Load Factor may limit the total number that you can install. Refer to
the system’s Hardware Manual .
Telephone Extension Numbers 300-325 300-427
Telephone Station Numbers 34 (1-34) 128 (1-128)
Total Number of Station Devices 34
This includes digital extensions, analog
extensions, and analog Door Boxes.
128
May be limited by load factor.
Paging and Park
Page Zones (Internal) 7 zones (1-7) and All Call (0)
Page Zone (External) All Call and zone 1 broadcast from the Page audio minijack
Page Relays 2 in each built-in Door Box port
2 in each 2PGDAD Module (Future)
2 in each 2PGDAD Module (Future)
Park Orbits 10 (60-69)
Orbits 68 and 69 have extended (5 min.) timers
Passwords
System Administrator 1
(Level 1)
0000
System Administrator 2
(Level 2)
9999
Installer (Level 3) 632379 (NECDSX)
System Number Plan/Capacities (Page 2 of 2)
