This section provides an outline of options and peripheral equipment used with this inverter and
information on their reference manual.
This option is used in conjunction with a braking resistor to shorten the motor deceleration time.
This option detects the rotation speed of the motor with an encoder and feeds back the detected value
to enable high-accuracy operation with reduced speed variation, as well as position control via pulse
train position command input.
This is a Digital Operator with the 5-line display capability.
This optional support tool enables you to edit inverter parameter data and monitor the status of the
inverter.
This option enables a stand-alone inverter to perform simple sequence control.
2-3-11 Reference Manuals for Options
Regenerative Braking Unit (Model: 3G3AX-RBU)
Name Catalog No.
Regenerative Braking Unit 3G3AX-RBU User’s Manual I563
PG Board (Model: 3G3AX-PG01)
Name Catalog No.
Encorder Feedback Board 3G3AX-PG User’s Manual I564
LCD Digital Operator (Model: 3G3AX-OP05)
Name Catalog No.
LCD Digital Operator 3G3AX-OP05 User’s Manual I579
CX-Drive
Name Catalog No.
CX-Drive Operation Manual W453
DriveProgramming
Name Catalog No.
DriveProgramming User’s Manual I580
