Omron RX Series - 12-16 Devicenet Communications Unit (Model: 3 G3 AX-RX-DRT-E); Specifications; Devicenet Communications Unit (Model: 3 G3 AX-RX-DRT-E)

12 - 63
12 Options
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
12-16 DeviceNet Communications Unit
(Model: 3G3AX-RX-DRT-E)
12
12-16-1 Specifications
12-16 DeviceNet Communications Unit
(Model: 3G3AX-RX-DRT-E)
12-16-1 Specifications
Item Specifications
Mounting
Unit type RX Series DeviceNet Communications Unit
Model 3G3AX-RX-DRT-E
Dimensions
[Width x Height x Depth]
80 × 67 × 49 mm
Weight Approx. 170 g
Environment
Operating ambient
temperature
–10 to 50°C (with no freezing or condensation)
Operating ambient humidity 20% to 90%
Storage ambient temperature –20 to 65°C (with no freezing or condensation)
Vibration resistance
5.9 m/s
2
(0.6 G), 10 to 55 Hz
Dielectric strength 500 VAC (between isolated circuits)
Location At a maximum altitude of 1,000 m (without corrosive gases or dust)
Conformance to EMC and
electrical safety standards
EN61800-3: 2004 (2004/108/EC) Second environment, Category C3
EN61800-5-1: 2007 (2006/95/EC) SELV
Enclosure rating IP20
DeviceNet
interface
Communications protocol DeviceNet
Certification DeviceNet conformance test
DeviceNet profile AC drive (0x02)
Supported connections
Remote I/O: Master-Slave connection
Poll
Explicit message
Conforming to the DeviceNet specifications
Communications power
supply
11 to 25 VDC (50 mA max., 20 mA typ.)
Unit device address range Node address MAC ID 0 to 63, set via Inverter parameter P192
Supported baud rates
125, 250, or500 kbps
Automatic baud rate detection by Master Unit
DeviceNet
configuration
Default connection path Supported, set via Inverter parameter P046
Supported assemblies
Basic Speed I/O (Output assembly 20, Input assembly 70)
Extended Speed I/O (21, 71)
Extended Speed and Torque Control (123, 173)
Special I/O (100, 150)
Extended Control I/O (101, 151)
Extended Control I/O and Multi-function Input Monitor (101, 153)
Flexible Format (139, 159)
Extended Speed and Acceleration Control (110, 111)
In case the DeviceNet Master Unit is configured using user allocation, only the
input/output pairs can be configured.
EDS file Dependent on Inverter model
