Omron RX Series - Specifications; Standard Specifications

1 - 9
1 Overview
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
1-3 Specifications
1
1-3-1 Standard Specifications
1-3 Specifications
CT: Heavy load mode, VT: Light load mode
1-3-1 Standard Specifications
3-phase 200-V Class
Item
Model (3G3RX)
A2004-V1 A2007-V1 A2015-V1 A2022-V1 A2037-V1 A2055-V1 A2075-V1 A2110-V1
Maximum applicable motor
capacity [kW]
CT 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
VT 0.75 1.5 2.2 3.7 5.5 7.5 11 15
Rated output capacity
[kVA]
200 V
CT 1.0 1.7 2.5 3.6 5.7 8.3 11.0 15.9
VT 1.2 2.1 3.2 4.1 6.7 10.3 15.2 20.0
240 V
CT 1.2 2.0 3.1 4.3 6.8 9.9 13.3 19.1
VT 1.5 2.6 3.9 4.9 8.1 12.4 18.2 24.1
Rated input voltage 3-phase: 200 V –15% to 240 V 10%, 50/60 Hz ±5%
Rated input current [A]
CT3.35.58.31218263551
VT 3.9 7.2 10.8 13.9 23 37 48 64
Rated output voltage 3-phase: 200 to 240 V (Cannot exceed that of incoming voltage)
Rated output current [A]
CT 3.0 5.0 7.5 10.5 16.5 24 32 46
VT3.76.39.41219.6304458
EMC noise filter Built-in (EMC Directive EN61800-3 Category C3)
Weight [kg] 3.5 3.5 3.5 3.5 3.5 6 6 6
Braking
Regenerative braking Built-in braking resistor circuit (Discharge resistor separately mounted)
Minimum connection
resistance [Ω]
50 50 35 35 35 16 10 10
Maximum
leakage
current [mA]
EMC filter enabled 2.5 48
EMC filter disabled 0.1
Item
Model (3G3RX)
A2150-V1 A2185-V1 A2220-V1 A2300-V1 A2370-V1 A2450-V1 A2550-V1
Maximum applicable motor capacity [kW]
CT1518.52230374555
VT18.5223037455575
Rated input capacity [kVA]
200 V
CT 22.1 26.3 32.9 41.9 50.2 63.0 76.2
VT 25.2 29.4 39.1 48.5 58.5 72.7 93.5
240 V
CT 26.6 31.5 39.4 50.2 60.2 75.6 91.4
VT 30.3 35.3 46.9 58.1 70.2 87.2 112.2
Rated input voltage 3-phase: 200 V –15% to 240 V 10%, 50/60 Hz ±5%
Rated input current [A]
CT 70 84 105 133 160 200 242
VT 80 94 120 150 186 240 280
Rated output voltage 3-phase: 200 to 240 V (Cannot exceed that of incoming voltage)
Rated output current [A]
CT 64 76 95 121 145 182 220
VT 73 85 113 140 169 210 270
EMC noise filter Built-in (EMC Directive EN61800-3 Category C3)
Weight [kg] 14 14 14 22 30 30 43
Braking
Regenerative braking
Built-in braking resistor circuit
(discharge resistor separately mounted)
Regenerative braking unit separately mounted
Minimum connection
resistance [
Ω]
7.5 7.5 5
–
Maximum leakage
current [mA]
EMC filter enabled 23
EMC filter disabled 0.1
