Omron RX Series - Warning Function

10 Troubleshooting
10 - 12
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
10-2 Warning Function
The following table shows the relationship between the displayed warning code and the parameter
correction.
Warning code Warning display conditions
W001 1st Frequency Upper Limit (A061) > 1st Maximum Frequency (A004)
W002 1st Frequency Lower Limit (A062) > 1st Maximum Frequency (A004)
W005
Output Frequency Setting/Monitor (F001),
1st Multi-step Speed Reference 0 (A020)
> 1st Maximum Frequency (A004)
W015
Output Frequency Setting/Monitor (F001),
1st Multi-step Speed Reference 0 (A020)
> 1st Frequency Upper Limit (A061)
W019
1st/2nd Frequency Upper Limit
(A061/A261)
< Orientation Speed Setting (P015)
W025
Output Frequency Setting/Monitor (F001),
1st Multi-step Speed Reference 0 (A020)
< 1st Frequency Lower Limit (A062)
W029 1st Frequency Lower Limit (A062) < Orientation Speed Setting (P015)
W031 1st Frequency Upper Limit (A061) < Starting Frequency (b082)
W032 1st Frequency Lower Limit (A062) < Starting Frequency (b082)
W035
Output Frequency Setting/Monitor (F001),
1st Multi-step Speed Reference 0 (A020)
< Starting Frequency (b082)
W037 Jogging Frequency (A038) < Starting Frequency (b082)
W085
Output Frequency Setting/Monitor (F001),
1st Multi-step Speed Reference 0 (A020)
<>
Jump Frequency 1/2/3 ± Jump Frequency Width 1/2/3
(A063/A065/A067) ± (A064/A066/A068)
W086
Multi-step Speed Reference 1 to 15
(A021 to A035)
<>
Jump Frequency 1/2/3 ± Jump Frequency Width 1/2/3
(A063/A065/A067) ± (A064/A066/A068)
W091 Free V/f Frequency 7 (b112) < 1st Frequency Upper Limit (A061)
W092 Free V/f Frequency 7 (b112) < 1st Frequency Lower Limit (A062)
W095 Free V/f Frequency 7 (b112) < 1st Multi-step Speed Reference 0 (A020)
W201 2nd Frequency Upper Limit (A261) > 2nd Maximum Frequency (A204)
W202 2nd Frequency Lower Limit (A262) > 2nd Maximum Frequency (A204)
W205
Output Frequency Setting/Monitor (F001),
2nd Multi-step Speed Reference 0 (A220)
> 2nd Maximum Frequency (A204)
W215
Output Frequency Setting/Monitor (F001),
2nd Multi-step Speed Reference 0 (A220)
> 2nd Frequency Upper Limit (A261)
W225
Output Frequency Setting/Monitor (F001),
2nd Multi-step Speed Reference 0 (A220)
< 2nd Frequency Lower Limit (A262)
W231 2nd Frequency Upper Limit (A261) < Starting Frequency (b082)
W232 2nd Frequency Lower Limit (A262) < Starting Frequency (b082)
W235
Output Frequency Setting/Monitor (F001),
2nd Multi-step Speed Reference 0 (A220)
< Starting Frequency (b082)
W285
Output Frequency Setting/Monitor (F001),
2nd Multi-step Speed Reference 0 (A220)
<>
Jump Frequency 1/2/3 ± Jump Frequency Width 1/2/3
(A063/A065/A067) ± (A064/A066/A068)
W291 Free V/f Frequency 7 (b112) < 2nd Frequency Upper Limit (A261)
W292 Free V/f Frequency 7 (b112) < 2nd Frequency Lower Limit (A262)
W295 Free V/f Frequency 7 (b112) < 2nd Multi-step Speed Reference 0 (A220)
W305
Output Frequency Setting/Monitor (F001),
3rd Multi-step Speed Reference 0 (A320)
> 3rd Maximum Frequency (A304)
W335
Output Frequency Setting/Monitor (F001),
3rd Multi-step Speed Reference 0 (A320)
< Starting Frequency (b082)
W385
Output Frequency Setting/Monitor (F001),
3rd Multi-step Speed Reference 0 (A320)
<>
Jump Frequency 1/2/3 ± Jump Frequency Width 1/2/3
(A063/A065/A067) ± (A064/A066/A068)
