6 Vector Control
6 - 52
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
• Set the forward/reverse position limit of the control range in the Position Limit Setting (Forward Side)
(P072)/Position Limit Setting (Reverse Side) (P073). If the current position counter exceeds the set
value, a Position control range error (E63.*/E73.*) will occur, which causes the inverter to fall into a
free-run state.
• The multi-step position command set in the Multi-step Position Command 0 to 7 (P060 to P067) is
subject to these upper limit settings.
You cannot set a position command value over the position limit setting.
Position Limit Setting Function
Parameter No. Function name Data Default data Unit
P072
Position Limit Setting
(Forward Side)
0 to 268435455 (When P012 = 02)
0 to 1073741823 (When P012 = 03)
(Displays MSB 4 digits)
268435455 –
P073
Position Limit Setting
(Reverse Side)
–268435455 to 0 (When P012 = 02)
–1073741823 to 0 (When P012 = 03)
Displays MSB 4digit (1 digit for “–”)
–268435455 –
