Omron RX Series - Option Board Protective Function List

10 - 9
10 Troubleshooting
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
10-1 Alarm Codes and
Remedies
10
10-1-3 Option Board Protective Function List
E6*. (OP1-*) appears when the option board is mounted on option port 1 (Digital Operator connecter
side), and E7*. (OP2-*) appears when it is mounted on option port 2 (control circuit terminal block
side).
 Function List for the DIP Switches on PG Board (Model: 3G3AX-PG01)
Use the DIP switches on the PG Board to enable/disable the encoder disconnection detection
function and terminating resistor.
Additional Information
Refer to the “Encorder Feedback Board 3G3AX-PG User’s Manual (I564)”.
10-1-3 Option Board Protective Function List
Protective Function Display when PG Board (Model: 3G3AX-PG01) is
Mounted
Name Description
Alarm code on
Digital Operator
Encoder disconnection
The inverter shuts off its output and displays an alarm if the
encoder wiring disconnection or connection failure is detected,
when the encoder is damaged, or when an encoder except for
line driver output is used.
E60., E70.
Overspeed
The inverter shuts off its output and displays an alarm if the
motor rotation speed reaches or exceeds the 1st Maximum
Frequency (A004) × the Overspeed Error Detection Level (P026).
E61., E71.
Positioning error
The inverter shuts off its the output and displays an alarm if the
current position deviation from the position reference value
reaches or exceeds 1,000,000 pulses during position control.
E62., E72.
Position control range
trip
The inverter shuts off its output and displays an alarm if the
current position exceeds the value set in the Position Limit
Setting (Forward Side) (P072) Position Limit Setting (Reverse
Side) (P073) during absolute position control.
E63., E73.
3G3AX-PG01
connection error
The inverter shuts off its output and displays an alarm if a PG
board connection (mounting) failure is detected.
E69., E79.
DIP switch Switch No. Description
SWENC
1ON
Disconnection detection enabled when encoder phase
A/B is not connected
2OFF
Disconnection detection disabled when encoder phase
A/B is not connected
1ON
Disconnection detection enabled when encoder phase
Z is not connected
2OFF
Disconnection detection disabled when encoder phase
Z is not connected
SWR
1ON
Terminating resistor between SAP and SAN (150 Ω)
enabled
2 OFF Terminating resistor between SAP and SAN disabled
1ON
Terminating resistor between SBP and SBN (150 Ω)
enabled
2 OFF Terminating resistor between SBP and SBN disabled
