5-6 Acceleration/Deceleration Time Settings
5
5-6-2 Acceleration/Deceleration Pattern
• Use this function to set the acceleration/deceleration pattern for each system.
• Select the acceleration and deceleration patterns in the Acceleration Pattern Selection (A097) and
Deceleration Pattern Selection (A098), respectively.
• The acceleration pattern and the deceleration pattern can be set independently.
• These acceleration/deceleration pattern settings are effective also for frequency reference via analog
input terminals.
5-6-2 Acceleration/Deceleration Pattern
Parameter
No.
Function name Data
Default
data
Unit
A097 Acceleration Pattern Selection
00: Line
01: S-shape curve
02: U-shape curve
03: Inverted U-shape curve
04: EL-S-shape curve
01
*1
*1.The default data was changed from the previous model.
–
A098 Deceleration Pattern Selection
A131 Acceleration Curve Parameter
01 (Small curve) to 10 (Large curve) 02 –
A132 Deceleration Curve Parameter
A150
EL-S Shape Acceleration Curve
Ratio 1
0. to 50.
10
*1
%
A151
EL-S Shape Acceleration Curve
Ratio 2
A152
EL-S Shape Deceleration Curve
Ratio 1
0. to 50.
10
*1
%
A153
EL-S Shape Deceleration Curve
Ratio 2
