12-13 PG Board (Model: 3G3AX-PG01)
12
12-13-1 Specifications
12-13 PG Board (Model: 3G3AX-PG01)
12-13-1 Specifications
Item Specifications
Speed Control
Encoder
feedback
Number of standard encoder pulses: 1024 pulses/rotation
Maximum number of input pulses: 100 Kpps
Speed control
method
Proportional integral (PI)/Proportional (P) control
Position control
Position
command
• The input mode of the pulse train is one of the following three types, which
can be specified as an Inverter setting.
Mode 0: 90° phase difference pulse
Mode 1: Forward/Reverse signal, pulse train
Mode 2: Forward pulse/Reverse pulse
• Maximum number of input pulses: 100 Kpps
Electronic gear
• Pulse ratio A/B (where A and B can take a value between 1 and 9999)
• Setting range: 1/50 ≤ A/B ≤ 20
Orientation
Stop position
• 4096 divisions per motor rotation
*1
*1. The inverter setting or external input is available. Note, however, that the DI Board (Model: 3G3AX-DI) is required
separately for external input.
Speed • Orientation speed and rotation speed settings available
Protective function
• Encoder cable disconnection protection
• Overspeed protection (Overspeed Error Detection Level (P026))
• Positioning error
• 3G3AX-PG connection error
