5 - 3
5 Basic Settings
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
5-1 Parameter Display and Parameter Initialization
5
5-1-1 Display Selection
5-1 Parameter Display and Parameter
Initialization
• You can select the parameters to be displayed on the Digital Operator.
• To display all parameters, set the Display Selection to 00 (Complete display).
Displays all inverter parameters.
If a specific function is not selected, its related parameter is not displayed.
For details on the display conditions, refer to the following table.
5-1-1 Display Selection
Parameter No. Function name Data
Default
data
Unit
b037 Display Selection
00: Complete display
01: Individual display of functions
02: User setting + b037
03: Data comparison display
04: Basic display
00
*1
*1. The default data was changed from the previous model.
–
U001 to U012
User Selection 1
to User Selection
12
no: No registration
d001 to P196: Select the parameter
number you want to display.
no –
Complete Display (b037 = 00)
Individual Display of Functions (b037 = 01)
No. Display condition
Parameters displayed when display condition is met
1 A001 = 01
A005, A006, A011 to A016, A101, A102
A111 to A114, C081 to C083, C121 to C123
2 A001 = 10 A141 to A143
3 A002 = 01, 03, 04, 05 b087
4 A017 = 01
d025 to d027, P100 to P131
P100 to P131 cannot be used.
5 A041 = 01 A046, A047
6 A044 = 00, 01 A041, A042, A043
7 A044 = 03, 04, 05 H002, H005, H050
8 A044 = 04 H060, H061
9 A044 = 03, 04, 05, and H002 = 00 H020 to H024
10 A044 = 03, 04, 05, and H002 = 01, 02 H030 to H034
11
Either A044 or A244, or both of them are 03, 04,
05.
d008 to d010, d012, b040 to b046, H001, H070 to H073
12 Either A044 or A244, or both of them are 02. b100 to b113
13 A051 = 01, 02 A052, A056 to A058
14 A051 = 01, 02 A053 to A055, A059
