4 Parameter List
4 - 6
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
4-3 Extended Function Mode
In the extended function mode, inverter parameters are categorized in five groups: A, b, C, H, and P.
This section provides the parameter list for each group.
Note that the parameters displayed on the Digital Operator depend on the setting in the Display
Selection (b037). To display all parameters, set this parameter to 00 (Complete display).
Precautions for Correct UsePrecautions for Correct Use
• You can change the parameter display on the Digital Operator by the Display Selection (b037).
For details, refer to Display Selection on page 7-78.
• In the 3G3RX-V1, the factory setting for the Display Selection (b037) is “Complete display,”
which was changed from the conventional default “Basic display.” You can see and set all
parameters when you turn on the power supply for the first time.
• You can set the initial screen displayed after turning on the power supply by the Initial Screen
Selection (b038). For details, refer to Initial Screen Selection (Initial Screen after Power-on) on
page 7-81.
• You can display only the parameters registered as user parameters. It is also possible to
automatically register changed parameters, or directly set specific parameters. For details,
refer to User Parameter Automatic Setting Function on page 7-81.
To Next Page
