12 Options
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
12-3 Braking Resistor
(Model: 3G3AX-RBA/RBB/RBC)
12
12-3-3 Connection Example
For how to connect regenerative braking unit(s), refer to External Braking Resistor Connection Terminal
(P/+2, RB)/ Regenerative Braking Unit Connection Terminal (P/+2, N/–) on page 2-39 in this manual.
3G3AX-RBC12001
12-3-3 Connection Example
150
170
7
110
10390
410
PRB
AL1
AL2
Terminal width 9 mm
Screw M4
Terminal block
Terminal
block
