High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
12-10 EMC Noise Filter
(Model: 3G3AX-EFI)
12-10-1 Specifications
Inverter EMC noise filter specifications
Voltage
class
Max.
applicable
motor
capacity
[kW]
Model
Heavy/
Light load
mode
Max.
applicable
motor
capacity
[kW]
Rated
input
current
[A]
Model
Max.
input
voltage
Rated
input
current
[A]
Heat
generation
[W]
Leakage
current
(at 480 VAC
60 Hz)
Class
200-V
class
0.4
3G3RX-
A2004-V1
Heavy load 0.4 3.3
3G3AX-
EFI41
480
VAC
+10%
74
150 mA
max.
A
Light load 0.75 3.9
0.75
3G3RX-
A2007-V1
Heavy load 0.75 5.5
Light load 1.5 7.2
3G3AX-
EFI42
10 4
150 mA
max.
1.5
3G3RX-
A2015-V1
Heavy load 1.5 8.3
Light load 2.2 10.8
3G3AX-
EFI43
20 8
170 mA
max.
2.2
3G3RX-
A2022-V1
Heavy load 2.2 12
Light load 3.7 13.9
3.7
3G3RX-
A2037-V1
Heavy load 3.7 18
Light load 5.5 23
3G3AX-
EFI44
30 9
170 mA
max.
5.5
3G3RX-
A2055-V1
Heavy load 5.5 26
Light load 7.5 37
3G3AX-
EFI45
40 15
170 mA
max.
7.5
3G3RX-
A2075-V1
Heavy load 7.5 35
Light load 11 48
3G3AX-
EFI47
60 15
250 mA
max.
11
3G3RX-
A2110-V1
Heavy load 11 51
Light load 15 64
3G3AX-
EFI48
80 21
250 mA
max.
15
3G3RX-
A2150-V1
Heavy load 15 70
Light load 18.5 80
3G3AX-
EFI49
100 23
250 mA
max.
18.5
3G3RX-A-
2185-V1
Heavy load 18.5 84
Light load 22 94
3G3AX-
EFI4A
150 45
250 mA
max.
22
3G3RX-
A2220-V1
Hea
vy load 22 105
Light load 30 120
30
3G3RX-
A2300-V1
Hea
vy load 30 133
Light load 37 150
3G3AX-
EFI4B
200 50
250 mA
max.
37
3G3RX-
A2370-V1
Heavy load 37 160
Light load 45 186 – – – – – –
