Omron RX Series - Basic Function Mode; Group F: Basic Function Parameters

4 - 5
4 Parameter List
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
4-2 Basic Function Mode
4
4-2-1 Group F: Basic Function Parameters
4-2 Basic Function Mode
The table below lists the basic function mode parameters.
*1 The default data was changed from the previous model.
Description for Data Range
4-2-1 Group F: Basic Function Parameters
Parameter
No.
Function name Monitor or data range
Default
data
Changes during
operation
Unit Page
Normal b031 = 10
F001 Output Frequency
Setting/Monitor
0.0/Starting frequency to
1st/2nd/3rd max. frequency
0.0 to 100.0 (PID function enabled)
– Enabled Enabled Hz 7-14
F002 1st Acceleration
Time 1
0.01 to 99.99
100.0 to 999.9
1000. to 3600.
10.0
*1
Enabled Enabled s 7-15
F202 2nd Acceleration
Time 1
10.0
*1
Enabled Enabled s
F302 3rd Acceleration
Time 1
10.0
*1
Enabled Enabled s
F003 1st Deceleration
Time 1
0.01 to 99.99
100.0 to 999.9
1000. to 3600.
10.0
*1
Enabled Enabled s
F203 2nd Deceleration
Time 1
10.0
*1
Enabled Enabled s
F303 3rd Deceleration
Time 1
10.0
*1
Enabled Enabled s
F004 RUN Direction
Selection
00: Forward
01: Reverse
00 Disabled Disabled – 7-16
Data range Description
0.00 to 99.99 Displays in increments of 0.01.
0.0 to 999.9 Displays in increments of 0.1.
0. to 9999. Displays in increments of 1.
1000 to 9999 (10000 to 99990) Displays in increments of 10.
Γ100 to Γ999 (100000 to 999000) Displays in increments of 1000.
