4 Parameter List
4 - 4
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
*1 This can be displayed when the LCD Digital Operator is used.
Description for Data Range
Display of MSB 4 Digits
d031
*1
Current Time
Monitor
mm/dd hh: mm
(Month/Day and Hours/Minutes,
12 characters)
– –––7-11
d060 Inverter Mode
Monitor
Displays currently set mode
I-C: IM motor heavy load
I-V: IM motor light load
– –––7-11
d080 Fault Counter 0. to 9999.
1000 to 6553
(10000 to 65530)
– ––time7-11
d081 Fault Monitor 1
(Latest)
Error code (Fault factor)
• Output frequency [Hz]
• Output current [A]
• P-N voltage [V]
• RUN time [h]
• Power ON time [h]
– –––7-12
d082 Fault Monitor 2 – – – –
d083 Fault Monitor 3 – – – –
d084 Fault Monitor 4 – – – –
d085 Fault Monitor 5 – – – –
d086 Fault Monitor 6 – – – –
d090 Warning Monitor Warning code – – – – 7-12
d102 DC Voltage
Monitor
0.0 to 999.9 – – – V 7-13
d103 Regenerative
Braking Load
Rate Monitor
0.0 to 100.0 – – – % 7-13
d104 Electronic
Thermal Load
Rate Monitor
0.0 to 100.0 – – – % 7-13
Data range Description
0.00 to 99.99 Displays in increments of 0.01.
0.0 to 999.9 Displays in increments of 0.1.
0. to 9999. Displays in increments of 1.
1000 to 9999 (10000 to 99990) Displays in increments of 10.
Γ100 to Γ999 (100000 to 999000) Displays in increments of 1000.
Data Display
1230000 1230
–1230000 –123
Parameter
No.
Function name Monitor or data range
Default
data
Changes during
operation
Unit Page
Normal
b031 = 10
