12-7 Input Noise Filter (Model: 3G3AX-NFI)
12
12-7-2 External Dimensions
12-7-2 External Dimensions
Model Case, enclosure rating Terminal size Wire diameter Weight [kg]
G3AX-NFI21 Plastic, IP00 M4
1.25 mm
2
0.5
3G3AX-NFI22 Plastic, IP00 M4
2 mm
2
0.6
3G3AX-NFI23 Plastic, IP00 M4
2 mm
2
, 3.5 mm
2
0.7
3G3AX-NFI24 Plastic, IP00 M4
5.5 mm
2
0.8
3G3AX-NFI25 Plastic, IP00 M5
8 mm
2
1.4
3G3AX-NFI26 Plastic, IP00 M5
14 mm
2
1.8
3G3AX-NFI27 Metal, IP00 M6
22 mm
2
3.6
3G3AX-NFI28 Metal, IP00 M8
30 mm
2
4.6
3G3AX-NFI29 Metal, IP00 M8
38 mm
2
, 60 mm
2
9.0
3G3AX-NFI2A Metal, IP00 M10
100 mm
2
or 38 mm
2
, 2 wires parallel
16
3G3AX-NFI2B Metal, IP00 M10
100 mm
2
or 38 mm
2
, 2 wires parallel
16
3G3AX-NFI2C Metal, IP00 M10
150 mm
2
or 60 mm
2
, 2 wires parallel
23
3G3AX-NFI41 Plastic, IP00 M4
1.25 mm
2
, 2 mm
2
0.7
3G3AX-NFI42 Plastic, IP00 M4
2 mm
2
0.7
3G3AX-NFI43 Plastic, IP00 M4
2 mm
2
, 3.5 mm
2
0.7
3G3AX-NFI44 Plastic, IP00 M4
5.5 mm
2
0.8
3G3AX-NFI45 Plastic, IP00 M5
8 mm
2
1.4
3G3AX-NFI46 Plastic, IP00 M5
14 mm
2
1.6
3G3AX-NFI47 Plastic, IP00 M5
14 mm
2
1.8
3G3AX-NFI48 Metal, IP00 M6
22 mm
2
3.6
3G3AX-NFI49 Metal, IP00 M8
38 mm
2
4.6
3G3AX-NFI4A Metal, IP00 M8
38 mm
2
, 60 mm
2
9.0
