• Set the multi-function output P1 to P5 terminals and the multi-function relay output (MA, MB) terminal
to either NO (Normally open contact) or NC (Normally closed contact) individually.
• Each multi-function output terminal can be allocated with the ON/OFF delay time.
• All output signals turn ON/OFF immediately when the set conditions are satisfied. Depending on the
selected signal, chattering may occur. In such a case, use this function to hold or delay the signal.
• Set the parameter for each output terminal. For the output terminal, multi-function output terminals
P1 to P5 and a multi-function relay output (MA, MB) terminal are provided. For the output terminals
and the corresponding parameters, refer to the table below.
5-10-2 Multi-function Output Operation Selection
Parameter
No.
Function name Data Default data Unit
C031
Multi-function Output P1
Operation Selection
00: NO (Normally open contact)
01: NC (Normally closed contact)
00 –
C032
Multi-function Output P2
Operation Selection
C033
Multi-function Output P3
Operation Selection
C034
Multi-function Output P4
Operation Selection
C035
Multi-function Output P5
Operation Selection
C036
Multi-function Relay Output
(MA, MB) Operation
Selection
00: NO contact between MA and
MC, NC contact between MB
and MC
01: NC contact between MA and
MC, NO contact between MB
and MC
01 –
5-10-3 Multi-function Output ON/OFF Delay Time
Parameter
No.
Function name Data Default data Unit
C130 Multi-function Output P1 ON Delay Time
0.0 to 100.0 0.0 s
C132 Multi-function Output P2 ON Delay Time
C134 Multi-function Output P3 ON Delay Time
C136 Multi-function Output P4 ON Delay Time
C138 Multi-function Output P5 ON Delay Time
C140 Multi-function Relay Output ON Delay Time
C131 Multi-function Output P1 OFF Delay Time
0.0 to 100.0 0.0 s
C133 Multi-function Output P2 OFF Delay Time
C135 Multi-function Output P3 OFF Delay Time
C137 Multi-function Output P4 OFF Delay Time
C139 Multi-function Output P5 OFF Delay Time
C141 Multi-function Relay Output OFF Delay Time
