1 Overview
1 - 10
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
CT: Heavy load mode, VT: Light load mode
3-phase 400-V Class
Item
Model (3G3RX)
A4004
-V1
A4007
-V1
A4015
-V1
A4022
-V1
A4037
-V1
A4055
-V1
A4075
-V1
A4110
-V1
A4150
-V1
A4185
-V1
A4220
-V1
Maximum applicable motor
capacity [kW]
CT 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
VT 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30
Rated output capacity
[kVA]
400 V
CT 1.0 1.7 2.6 3.6 6.2 9.6 13.1 17.3 22.1 26.3 33.2
VT 1.3 2.1 3.3 4.6 7.6 11.0 15.2 20.0 25.6 29.7 39.4
480 V
CT 1.2 2.0 3.1 4.4 7.4 11.6 15.7 20.7 26.6 31.5 39.9
VT 1.5 2.5 3.9 5.5 9.2 13.3 18.2 24.1 30.7 35.7 47.3
Rated input voltage 3-phase: 380 V –15% to 480 V 10%, 50/60 Hz ±5%
Rated input current [A]
CT1.82.84.25.89.8152128354253
VT2.14.35.98.113.3202432414763
Rated output voltage 3-phase: 380 to 480 V (Cannot exceed that of incoming voltage)
Rated output current [A]
CT1.52.53.85.39.0141925323848
VT1.93.14.86.711.1162229374357
EMC noise filter Built-in (EMC Directive EN61800-3 Category C3)
Weight [kg] 3.53.53.53.53.5666141414
Braking
Regenerative braking Built-in braking resistor circuit (Discharge resistor separately mounted)
Minimum connection
resistance [Ω]
100 100 100 100 70 70 35 35 24 24 20
Maximum
leakage
current [mA]
EMC filter enabled
59556
EMC filter disabled
0.2
Item
Model (3G3RX)
A4300
-V1
A4370
-V1
A4450
-V1
A4550
-V1
A4750
-V1
B4900
-V1
B411K
-V1
B413K
-V1
Maximum applicable motor
capacity [kW]
CT 30 37 45 55 75 90 110 132
VT 37 45 55 75 90 110 132 160
Rated output capacity
[kVA]
400 V CT 40.1 51.9 63.0 77.5 103.2 121.9 150.3 180.1
VT 48.4 58.8 72.7 93.5 110.8 135 159.3 200.9
480 V CT 48.2 62.3 75.6 93.1 123.8 146.3 180.4 216.1
VT 58.1 70.6 87.2 112.2 133 162.1 191.2 241.1
Rated input voltage 3-phase: 380 V –15% to 480 V 10%, 50/60 Hz ±5%
Rated input current [A]
CT 64 83 100 121 164 194 239 286
VT 77 94 116 149 176 199 253 300
Rated output voltage 3-phase: 380 to 480 V (Cannot exceed that of incoming voltage)
Rated output current [A]
CT 58 75 91 112 149 176 217 260
VT 70 85 105 135 160 195 230 290
EMC noise filter Built-in (EMC Directive EN61800-3 Category 3)
Weight [kg] 22 30 30 30 55 55 70 70
Braking
Regenerative braking Regenerative braking unit separately mounted
Minimum connection
resistance [Ω]
–
Maximum
leakage
current [mA]
EMC filter enabled 56
0.2 (No enabled/disabled setting
available)
EMC filter disabled 0.2
