7 Detailed Functions
7 - 148
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
• In the Operation Selection at Idle Mode Detection (P048), set how the inverter should operate when
the network is in the Idle (communications standby) mode.
• Use these parameters to set user-defined values available with the DriveProgramming function.
• Changes made to DriveProgramming User Parameters via the Digital Operator are reflected on the
user variables (U00 to U31) used in the program.
• For details, refer to “DriveProgramming User
’s Manual (I580)”.
Parameter No. Function name Data Default data Unit
P044
Communications Error
Detection Timer Setting
0.00 to 99.9 1.00 s
P045
Operation Selection at
Host Communications
Error
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free-run stop
04: Deceleration stop
00 –
P046
Assembly Instance
Number
00 to 20 01 –
P048
Operation Selection at
Idle Mode Detection
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free-run stop
04: Deceleration stop
00 –
P049
Number of Poles for
Rotation Speed Setting
0/2/4/8/10/12/14/16/18/20/22/24/26/
28/30/32/34/36/38
0–
P160 to P169
Option I/F Flexible
Format Output Register
1 to 10
0000 to FFFF 0000 –
P170 to P179
Option I/F Flexible
Format Input Register 1
to 10
0000 to FFFF 0000 –
P190
CompoNet Node
Address
0 to 63 00 –
P192 DeviceNet MAC ID 0 to 63 63 –
DriveProgramming Unser Parameters
Parameter No. Function name Data Default data Unit
P100 to P131
DriveProgramming User
Parameter U00 to U31
0. to 9999.
1000 to 6553 (10000 to 65535)
0. –
