1 Overview
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
1-5 Comparison with Previous
Model
1
The default parameter setting of the conventional 3G3RX Series Inverter were reviewed and were
changed according to the user’s usage. Some functions are enabled by default for reducing the
workload of the user.
The default parameter setting changed in the 3G3RX-V1 Series are shown in Section 4 Parameter List.
Check if these are appropriate for your application.
Change of Default Parameter Setting
No. Parameter name
Default setting change
No. Parameter name
Default setting change
Conventional 3G3RX-V1 Conventional 3G3RX-V1
F002 1st Acceleration Time
1
30.00 10.00 A097 Acceleration Pattern
Selection
00 01
F202 2nd Acceleration
Time 1
30.00 10.00 A098 Deceleration Pattern
Selection
00 01
F302 3rd Acceleration Time
1
30.00 10.00 A150 EL-S Shape
Acceleration Curve
Ratio 1
25 10
F003 1st Deceleration Time
1
30.00 10.00 A151 EL-S Shape
Acceleration Curve
Ratio 2
25 10
F203 2nd Deceleration
Time 1
30.00 10.00 A152 EL-S Shape
Deceleration Curve
Ratio 1
25 10
F303 3rd Deceleration Time
1
30.00 10.00 A153 EL-S Shape
Deceleration Curve
Ratio 2
25 10
A039 Jogging Stop
Selection
00 04 b006 Input Phase Loss
Protection Selection
00 01
A041 1st Torque Boost
Selection
00 01 b037 Display Selection 04 00
A241 2nd Torque Boost
Selection
00 01 b082 Starting Frequency 0.50 1.50
A047 1st Automatic Torque
Boost Slip
Compensation Gain
100 0 b130 Overvoltage
Suppression Function
Selection During
Deceleration
00 01
A247 2nd Automatic Torque
Boost Slip
Compensation Gain
100 0 C071 Communication
Speed Selection
(Baud Rate Selection)
04 05
A092 1st Acceleration Time
2
30.00 10.00 C073 Communication Bit
Length Selection
78
A292 2nd Acceleration
Time 2
30.00 10.00 C102 Reset Selection 00 02
A392 3rd Acceleration Time
2
30.00 10.00 P070 Origin Search Mode 1
Frequency
0.00 5.00
A093 1st Deceleration Time
2
30.00 10.00 P071 Origin Search Mode 2
Frequency
0.00 5.00
A293 2nd Deceleration
Time 2
30.00 10.00
A393 3rd Deceleration Time
2
30.00 10.00
