QNAP QTS 4.5 Series User Manual

• You can convert a CA certificate to a public key using a Linux environment or an OpenSSL.
7. Click Apply.
Note
Your NAS login screen changes to include an Azure SSO login option.
LDAP Authentication
A Lightweight Directory Access Protocol (LDAP) directory contains user and user group information stored
on an LDAP server. Administrators can use LDAP to manage users in the LDAP directory and connect to
multiple NAS devices with the same login details. This feature requires a running LDAP server and
knowledge of Linux servers, LDAP servers, and Samba.
Configuring LDAP Authentication
1. Go to Control Panel > Privilege > Domain Security .
2. Select LDAP authentication.
3. Select the type of LDAP server.
4. Specify the following information.
LDAP Server Type Fields User Action
Remote LDAP server LDAP Server Host Specify the host name or IP address of the LDAP
server.
LDAP Security Select the method that the NAS uses to communicate
with the LDAP server.
• ldap://: Use a standard LDAP connection. The
default port is 389.
• ldap:// (ldap + TLS): Use an encrypted
connection with TLS. The default port is 389.
Newer versions of LDAP servers normally use
this port.
• ldap:// (ldap + SSL): Use an encrypted
connection with SSL. The default port is 686.
Older versions of LDAP servers normally use
this port.
Base DN Specify the LDAP domain.
Example: dc=mydomain,dc=local
Root DN Specify the LDAP root user.
Example: cn=admin, dc=mydomain,dc=local
Password Specify the root user password.
Users Base DN Specify the Organizational unit (OU) where users are
stored.
Example: ou=people,dc=mydomain,dc=local
Group Base DN Specify the OU where groups are stored.
Example: ou=group,dc=mydomain,dc=local
Current Samba ID N/A
QTS 4.5.x User Guide
Privilege Settings 102
