Chapter 4 Configuring Your Library
Configuring Devices
Scalar i2000 User’s Guide 149
The drive shown in both of these figures is in the topmost of the twelve
drive bays in a control module. The following figure shows its location in
the control module. For more information about location coordinates, see
Understanding Location Coordinates on page 366.
4 To specify a particular ID for a drive, perform one of the following
tasks:
f For a FC drive, either click a new ID number from the New ID
drop-down list or select the Soft check box to automatically
assign an ID.
g For a SCSI drive, click a new ID number from the New ID drop-
down list.
5 Click Set.
(1,1,1,12,1,1)
Drive 1
Drive 2
Drive 3
Drive 4
Drive 5
Drive 6
Drive 7
Drive 8
Drive 9
Drive 10
Drive 11
Drive 12
