Chapter 5 Maintaining Your Library
Maintenance Actions
Scalar i2000 User’s Guide 252
The Email, Save or Print Table dialog box appears.
7 Perform one of the following tasks:
• To indicate that you want to send the snapshot as an e-mail
message to a recipient, select Email, and then either type an e-
mail address in the Email text box or select an existing e-mail
address from the Email drop-down list. You can type a comment
in the Comment text box to send with the snapshot.
• To indicate that you want to save the snapshot, select Save, and
then either type in the Save text box a path and a file name to
which you want the snapshot saved or click Browse to specify a
location and a file name.
8 To send, click OK.
Typically, you should send the snapshot to
Quantum technical support (
www.quantum.com/
support) when requested to do so.
The Save option is available to remote client users
only. It appears grayed out on the touch screen.
