Quantum Scalar i2000

Chapter 5 Maintaining Your Library
Maintenance Actions
Scalar i2000 User’s Guide 298
Scan Fiducials 5
The scan fiducials graphical report shows the results for tests of the
fiducial barcode on each tape magazine and drive sled, including the
width, expected Y position (shift), and the number of hits the scanner
receives while traveling up and down. (Only known magazines are
tested.)
• If the graphical report shows a failed result for one or more tape
magazines, replace the affected magazines.
• If there are multiple marginal or failed results, run the library
alignment test (part of the installation verification or partial frame
test) to make sure the library is level.
• If the library is level and there are multiple marginal or failed results,
the scanner should be inspected and replaced if necessary.
See figure 28 on page 299.
