Chapter 6 Running Your Library
Understanding Location Coordinates
Scalar i2000 User’s Guide 371
Figure 41 on page 372 shows examples of location coordinates. These
examples assume that the linear storage is located in aisle 1, module 1, and
rack 1. That is why the first three numbers in the comma separated list are
1,1,1. The last three numbers represent the address on the linear storage
assembly.
In figure 40 on page 370, the five magazines shown
in column 4, sections 6-10 do not exist in a control
module. However, these magazines exist in
expansion modules.
