the single-ended analyzer port no. 2 as a source port.
SOURce<Ch>:TDIF:TOLerance:AMPlitude <Tolerance>
Defines the amplitude tolerance for the True Differential Mode (and the Defined Coherence Mode; see
also SOURce<Ch>:CMODe:TOLerance:AMPlitude).
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Tolerance>
Amplitude tolerance
Range [def. unit]
0.01 dB to 1 dB
*RST value
0.1 dB
SCPI, Command Types
Device-specific, command or query
Example:
*RST; SOURce1:TDIF:TOLerance:AMPlitude 0.01 DB
SOURce<Ch>:TDIF:TOLerance:PHASe 0.1 DEG
Sets the tolerances to their minimum possible values
SOURce<Ch>:TDIF:TOLerance:PHASe <Tolerance>
Defines the phase tolerance for the True Differential Mode (and the Defined Coherence Mode; see also
SOURce<Ch>:CMODe:TOLerance:PHASe).
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Tolerance>
Phase tolerance
Range [def. unit]
0.1 deg to 10 deg
*RST value
1 deg
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:TDIF:TOLerance:AMPlitude <Tolerance>
SOURce<Ch>:TDIF:WAVes SENDed | DCMode
Qualifies whether the source power
(SOURce<Ch>:POWer<Pt>[:LEVel][:IMMediate][:AMPlitude]) is equal to the power of each
single-ended wave or to the balanced waves in true differential mode.
This is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
SENDed |
DCMode
Single-ended: Same Differential and Common Mode Voltages as in Single-
Ended Mode.
Differential and common mode: Apply to Differential (Zd = 2Z0) and Common
Mode (Zd = Z0/2) Waves.
*RST value
– (a reset leaves the setting unchanged)
