Range [def. unit]
Almost no restriction for limit segments; see Rules for Limit Line Definition. [Hz
for frequency sweeps, dBm for power sweeps, s for time sweeps]
*RST value
–
A segment that is created implicitly, e.g. by means of
CALCulate<Chn>:LIMit:UPPer[:DATA] or
CALCulate<Chn>:LIMit:LOWer[:DATA,], covers the maximum sweep
range of the analyzer.
SCPI, Command
Types
Confirmed, with query.
Example:
*RST; :CALC:LIM:CONT 1 GHZ, 2 GHZ
Define an upper limit line segment in the stimulus range between 1 GHz and 2
GHz, using default response values.
CALC:LIM:DISP ON
Show the limit line segment in the active diagram.
CALCulate<Chn>:LIMit:CONTrol:DOMain FLIN | FLOG | FSEG | FSINgle | TLIN |
TLOG | PLIN | PLOG | PSINgle
[Deprecated command, not needed on R&S ZVA]
Deletes the existing limit line and (re-)defines the physical units of the stimulus values of the limit line. The
units of the response values and the scaling of the y-axis are defined via
CALCulate<Chn>:LIMit:RDOMain:...
<Chn>
Channel number used to identify the active trace.
Parameters
Keywords for the units of the stimulus values.
The selected unit must be compatible with the sweep type
([SENSe<Ch>:]SWEep:TYPE); otherwise the limit line can not be displayed and
no limit check is possible.
Range [def. unit]
The parameters form three groups:
 FLIN, FLOG, FSEG, and FSINgle select frequency units [default: Hz] for
the limit line.
 TLIN and TLOG select time units [default: s].
 PLIN, PLOG and PSINgle select power units [default: dBm].
*RST value
FLIN
SCPI,
Command
Types
Device-specific, no query.
Example:
SWE:TYPE POW
Select a power sweep.
CALC:LIM:CONT:DOM PLIN
Delete all existing limit line segments and select level units for the limit line of the
active trace.
CALC:LIM:CONT -20 DBM, -10 DBM
