R&S ZVB - Page 651

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 636
1.5 GHz and 2 GHz, assigning response values of +2 dB and +3 dB.
CALC:LIM:SEGM:COUNT?
Query the number of segments. The response is 1.
CALCulate<Chn>:LIMit:SEGMent<Seg>:STIMulus:STARt <numeric_value>
Changes the start stimulus value (i.e. the smallest stimulus value) of a limit line segment. A segment must
be created first to enable this command (e.g CALC:LIM:DATA).
To define the stimulus values of several limit line segments with a single command, use
CALCulate<Chn>:LIMit:CONTrol[:DATA].
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
<numeric_value>
Frequency, power or time value, to be defined in accordance with the domain
setting (CALCulate<Chn>:LIMit:CONTrol:DOMain).
Range [def. unit]
Almost no restriction for limit segments; see Rules for Limit Line Definition.
[Hz for frequency sweeps, dBm for power sweeps, s for time sweeps]
*RST value
–
A segment that is created implicitly, e.g. by means of
CALCulate<Chn>:LIMit:UPPer[:DATA] or
CALCulate<Chn>:LIMit:LOWer[:DATA,], covers the maximum sweep
range of the analyzer.
SCPI, Command
Types
Device-specific, with query.
Example:
CALC:LIM:DATA 1,1500000000, 2000000000,2,3
Define an upper limit line segment (segment no. 1) in the stimulus range
between 1.5 GHz and 2 GHz, assigning response values of +2 dB and +3 dB.
CALC:LIM:SEGM:STIM:STAR 1GHZ; STOP 2 GHZ; :CALC:LIM:SEGM:TYPE LMIN
Change the segment to a lower limit line segment with a stimulus range
between 1 GHz and 2 GHz.
CALC:LIM:DATA?
Query the type, the stimulus and response values of the created segment with
a single command. The response is 2,1000000,2000000,2,3.
CALCulate<Chn>:LIMit:SEGMent<Seg>:STIMulus:STOP <numeric_value>
Changes the stop stimulus value (i.e. the largest stimulus value) of a limit line segment. A segment must
be created first to enable this command (e.g CALC:LIM:DATA).
To define the stimulus values of several limit line segments with a single command, use
CALCulate<Chn>:LIMit:CONTrol[:DATA].
