ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 637
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
<numeric_value>
Frequency, power or time value, to be defined in accordance with the domain
setting (CALCulate<Chn>:LIMit:CONTrol:DOMain).
Range [def. unit]
Almost no restriction for limit segments; see Rules for Limit Line Definition.
[Hz for frequency sweeps, dBm for power sweeps, s for time sweeps]
*RST value
–
A segment that is created implicitly, e.g. by means of
CALCulate<Chn>:LIMit:UPPer[:DATA] or
CALCulate<Chn>:LIMit:LOWer[:DATA,], covers the maximum sweep
range of the analyzer.
SCPI, Command
Types
Device-specific, with query.
Example:
See CALCulate<Chn>:LIMit:SEGMent<Seg>:STIMulus:STARt.
CALCulate<Chn>:LIMit:SEGMent<Seg>:TYPE LMIN | LMAX | OFF
Selects the limit line type for a limit line segment. This can be done before or after defining the stimulus
and response values of the segment, however, a segment must be created first to enable this command
(e.g CALC:LIM:DATA).
The type command overwrites the CALCulate<Chn>:LIMit:DATA settings and is overwritten by them.
It is not affected by the other commands in the LIMit subsystem defining stimulus and response values of
limit lines.
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
Parameters
Limit line type
Range [def. unit]
LMAX (upper limit line segment), LMIN (lower limit line segment), OFF (limit
check switched off, limit line segment not deleted) [–]
*RST value
LMAX
SCPI, Command
Types
Device-specific, with query.
Example:
*RST; :CALC:LIM:UPP 0, 0
Define an upper limit line segment across the entire sweep range, using a
constant upper limit of 0 dBm.
CALC:LIM:SEGM:TYPE LMIN
Turn the defined limit line segment into a lower limit line segment.
CALCulate<Chn>:LIMit:SOUNd[:STATe]
Switches the acoustic signal (fail beep) on or off. The fail beep is generated each time the analyzer
detects an exceeded limit.
