R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 656
range for a frequency sweep starts at 1 GHz.
CALC:MARK:REF ON
Create the reference marker and display it in the center of the sweep range.
CALC:MARK:REF:X 1GHz
Set the reference marker to the beginning of the sweep range.
CALCulate<Chn>:MARKer<Mk>:REFerence:Y?
Returns the response (in Cartesian diagrams: y-axis) value of the reference marker. The reference marker
must be created before using CALCulate<Chn>:MARKer<Mk>:REFerence[:STATe] ON.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. This numeric suffix is ignored and may be
set to any value.
Response
Response value of the reference marker
Range [def. unit]
Depending on the measured quantity. [unit depending on the marker format; see
CALCulate<Chn>:MARKer<Mk>:FORMat]
*RST value
–
SCPI,
Command
Types
Device-specific, query only
Example:
Suppose that the active setup contains an active trace no. 1.
CALC:MARK:REF ON
Create the reference marker and display it in the center of the sweep range.
CALC:MARK:REF:Y?
Query the measurement value at the reference marker position.
CALCulate<Chn>:MARKer<Mk>:SEARch:BFILter:RESult[:STATe] <Boolean>
Shows or hides the bandfilter search results in the diagram area.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. This numeric suffix is ignored and may be set to
any value.
<Boolean>
ON - Show the bandfilter search results. If no bandfilter search has been initiated
before (CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute BFILter),
nothing is displayed.
OFF - hide the bandfilter search results.
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query
