ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 683
CALCulate<Chn>:SMOothing...
This subsystem provides the settings for trace smoothing.
CALCulate<Chn>:SMOothing:APERture <numeric_value>
Defines how many measurement points are averaged to smooth the trace.
<Chn>
Channel number used to identify the active trace. If unspecified the numeric
suffix is set to 1.
<numeric_value>
Smoothing aperture.
Range [def. unit]
0.05% to 100%. A smoothing aperture of n % means that the smoothing
interval for each sweep point i with stimulus value x
i
is equal to [x
i
–
span*n/200, x
i
+ span*n/200], and that the result of i is replaced by the
arithmetic mean value of all measurement points in this interval. [%]
*RST value
1
SCPI, Command
Types
Device-specific, command or query.
Example:
*RST; :CALC:SMO ON
Activate smoothing for the default trace.
CALC:SMO:APER 0.5
Reduce the smoothing aperture to 0.5 %.
CALCulate<Chn>:SMOothing[:STATe] <Boolean>
Enables or disables smoothing for trace no. <Chn>.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - Smoothing on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:STATistics:SMOothing:APERture
CALCulate<Chn>:STATistics...
This subsystem evaluates and displays statistical and phase information of the trace.
CALCulate<Chn>:STATistics:DOMain:USER <range_no>
Selects one out of 10 evaluation ranges to be configured with the
