SCPI Command Reference
Operating Manual 1145.1084.12 – 30 682
To define several ripple limit ranges with a single command, use CALCulate<Chn>:RIPPle:DATA.
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
<stop_value>
Frequency, power or time value, to be defined in accordance with the sweep
type of the active channel.
Range [def. unit]
Almost no restriction for limit ranges; see Rules for Ripple Limit Definition.
[Hz for frequency sweeps, dBm for power sweeps, s for time sweeps]
*RST value
– (no ripple limit line defined after *RST)
SCPI, Command
Types
Device-specific, with query.
Example:
See CALCulate<Chn>:RIPPle:SEGMent<Seg>:STIMulus:STARt.
CALCulate<Chn>:RIPPle:SOUNd[:STATe] <Boolean>
Switches the acoustic signal (fail beep) on or off. The fail beep is generated each time the analyzer
detects an exceeded ripple limit.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - Fail beep on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
CALC:RIPP:STAT ON; SOUN ON
Switch the limit check on and activate the fail beep.
CALCulate<Chn>:RIPPle:STATe <Boolean>
Switches the ripple limit check for the active trace on or off.
Use CALCulate<Chn>:RIPPle:SEGMent<Seg>[:STATe] to switch the limit check for a single
ripple limit range on or off.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - ripple limit check on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:RIPPle:FAIL?
