CALCulate<Chn>:RIPPle:SEGMent<Seg>:STIMulus:STARt <start_value>
Changes the start stimulus value (i.e. the smallest stimulus value) of a ripple limit range. A range must be
created first to enable this command (e.g CALCulate<Chn>:RIPPle:DATA).
To define several ripple limit ranges with a single command, use CALCulate<Chn>:RIPPle:DATA.
<Chn>
Channel number used to identify the active trace.
<Seg>
Ripple limit range number
<start_value>
Frequency, power or time value, to be defined in accordance with the sweep
type of the active channel.
Range [def. unit]
Almost no restriction for limit ranges; see Rules for Ripple Limit Definition.
[Hz for frequency sweeps, dBm for power sweeps, s for time sweeps]
*RST value
– (no ripple limit line defined after *RST)
SCPI, Command
Types
Device-specific, with query.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000,3
Define and enable a ripple limit range in the stimulus range between 1.5 GHz
and 2 GHz, assigning a ripple limit of +3 dB.
CALC:RIPP:SEGM:STIM:STAR 1GHZ; STOP 2.5 GHZ; :CALC:RIPP:SEGM:LIM 5
Change the range to a stimulus range between 1 GHz and 2.5 GHz and a limit
of 5 dB.
CALC:RIPP:SEGM:STAT OFF
Disable the limit check in the modified stimulus range.
CALCulate<Chn>:RIPPle:SEGMent<Seg>[:STATe] <Boolean>
Enables or disables the limit check in the ripple limit range no. <Seg>.
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
<Boolean>
ON | OFF - Ripple limit check on or off. A result is available even if the limit check is
disabled; see example for CALCulate<Chn>:RIPPle:SEGMent<Seg>:RESult?.
*RST value
– (no ripple limit line defined after *RST)
SCPI,
Command
Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:RIPPle:SEGMent<Seg>:STIMulus:STARt.
CALCulate<Chn>:RIPPle:SEGMent<Seg>:STIMulus:STOP <stop_value>
Changes the stop stimulus value (i.e. the largest stimulus value) of a ripple limit range. A range must be
created first to enable this command (e.g CALCulate<Chn>:RIPPle:DATA).
