Note: If the start frequency entered is greater than the current stop frequency
(CALCulate<Chn>:TRANsform:TIME:STOP), the stop frequency is set to the start frequency plus the
minimum frequency span (CALCulate<Chn>:TRANsform:TIME:SPAN).
If the x-axis is scaled in distance units (CALCulate<Chn>:TRANsform:TIME:XAXis DISTance), then
the start value is entered in m; the range and default value changes accordingly.
CALCulate<Chn>:TRANsform:TIME:STATe <Boolean>
Determines whether the time domain transformation for trace no. <Chn> is enabled.
Channel number used to identify the active trace
ON – Time domain representation active
OFF – Frequency domain representation active
Confirmed, command or query
*RST; :CALC:TRAN:TIME:STAT?
Reset the instrument, activating a frequency sweep, and query whether the
default trace is displayed in the time domain. The response is 0.
CALCulate<Chn>:TRANsform:TIME:STIMulus STEP | IMPulse
Selects the type of stimulus to be simulated in the lowpass transformation process.
Channel number used to identify the active trace
IMPulse – Impulse response, in bandpass or lowpass mode
STEP – Step response, only in lowpass mode (a bandpass mode setting
CALCulate<Chn>:TRANsform:TIME[:TYPE] BPASs is automatically changed
to lowpass)
Confirmed, command or query
See CALCulate<Chn>:TRANsform:TIME[:TYPE]
CALCulate<Chn>:TRANsform:TIME:STOP <numeric_value>
Defines the stop time of the diagram in time domain.
Channel number used to identify the active trace
Stop time of the diagram.
–99.999999999998 s to +100 s. The increment (parameters UP or DOWN)
is 0.1 ns. [s]
