ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 694
CALCulate<Chn>:TRANsform:TIME:RESolution:EFACtor <factor>
Defines the resolution enhancement factor for the time domain transform.
<Chn>
Channel number used to identify the active trace
<factor>
Resolution enhancement factor.
Range [def. unit]
1 to 10. The increment (parameters UP or DOWN) is 0.1. [–]
*RST value
1 (no resolution enhancement)
SCPI, Command Types
Device-specific, command or query
Example:
See CALCulate<Chn>:TRANsform:TIME:LPASs:DCSParam
CALCulate<Chn>:TRANsform:TIME:SPAN <time_span>
Defines the time span of the diagram in time domain.
<Chn>
Channel number used to identify the active trace
<time_span>
Time span of the diagram in time domain.
Range [def. unit]
2E-012 s to 200 s. The increment (parameters UP or DOWN) is 0.1 ns. [s]
*RST value
5E-009 s
SCPI, Command Types
Confirmed, command or query
Example:
See CALCulate<Chn>:TRANsform:TIME:CENTer
Note: If the x-axis is scaled in distance units (CALCulate<Chn>:TRANsform:TIME:XAXis
DISTance), then the span is entered in m; the range and default value changes accordingly.
CALCulate<Chn>:TRANsform:TIME:STARt <start_time>
Defines the start time of the diagram in time domain.
<Chn>
Channel number used to identify the active trace
<start_time>
Start time of the diagram.
Range [def. unit]
–100 s to +99.999999999998 s. The increment (parameters UP or DOWN) is
0.1 ns. [s]
*RST value
–1E-009 s
SCPI, Command
Types
Confirmed, command or query
Example:
*RST; :CALC:TRAN:TIME:STAT ON
Reset the instrument, activating a frequency sweep, and enable the time
domain transformation for the default trace.
CALC:TRAN:TIME:STAR 0; STOP 10 ns
Set the start time to 0 ns and the stop time to 10 ns.
