<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
Parameters
Possible circuit models (character data); see circuit models.
*RST value
CSSL
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Ch>:TRANsform:VNETworks:BALanced:EMbedding[:STATe]
CALCulate<Ch>:TRANsform:VNETworks:GLOop:DEEMbedding:PARameters:C
SC, <capacitance>
Specifies the capacitance value for ground loop deembedding.
<Ch>
Channel number
Parameters
SC – Shunt C circuit model (character data); see circuit models.
<capacitance>
Capacitance C for ground loop deembedding.
Range [def. unit]
–1mF to 1 mF [F]. The increment is 1 fF (10
–15
F).
*RST value
1 pF (10
–12
F)
SCPI, Command
Types
Device-specific, command or query. In the query form, only the first parameter
is required; the <capacitance> must be omitted.
Example:
*RST; :CALC:TRAN:VNET:GLO:DEEM:PAR:C? SC
Query the default capacitance for ground loop deembedding. The response is
1E-012 (1 pF).
CALC:TRAN:VNET:GLO:DEEM:PAR:C SC, 2.2E-12
Increase the capacitance to 2.2 pF.
CALCulate<Ch>:TRANsform:VNETworks:GLOop:DEEMbedding:PARameters:L
SL, <inductance>
Specifies the inductance value for ground loop deembedding.
<Ch>
Channel number.
Parameters
SL – Shunt L circuit model (character data); see circuit models.
<inductance>
Inductance L for ground loop deembedding.
Range [def. unit]
–1H to 1 H [H]. The increment is 1 pH (10
–12
H).
*RST value
1 nH (10
–9
H)
SCPI, Command
Types
Device-specific, command or query. In the query form, only the first parameter
is required; the <inductance> must be omitted.
Example:
*RST; :CALC:TRAN:VNET:GLO:DEEM:PAR:L? SL
Query the default inductance for ground loop deembedding. The response is
1E-009 (1 nH).
