R&S ZVB - Page 720

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 705
CALC:TRAN:VNET:GLO:DEEM:PAR:L SL, 2.2E-9
Increase the inductance to 2.2 nH.
CALCulate<Ch>:TRANsform:VNETworks:GLOop:DEEMbedding:PARameters:R
SC | SL, <resistance>
Specifies the resistance value R in the different circuit models for ground loop deembedding.
<Ch>
Channel number.
Parameters
Possible circuit models (character data); see circuit models.
<resistance>
Resistance R for the specified circuit model.
Range [def. unit]
–10 MΩ to 10 MΩ [Ω]. The increment is 1 mΩ (10
–3
Ω).
*RST value
0 Ω if the resistance is connected in series with an inductance (SL)
10 MΩ if the resistance is connected in parallel with a capacitance (SC))
SCPI,
Command
Types
Device-specific, command or query. In the query form, only the first parameter is
required; the <resistance> parameter must be omitted. The command returns the
resistance value for the specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:GLO:DEEM:PAR:R? SC; R? SL
Query the default resistances for ground loop deembedding. The response is
10000000; 0.
CALC:TRAN:VNET:GLO:DEEM:PAR:R SC, 2.2E+3
Increase the resistance for the Shunt C model to 2.2 kΩ.
CALCulate<Ch>:TRANsform:VNETworks:GLOop:DEEMbedding[:STATe]
<Boolean>
Enables or disables the deembedding function for ground loops. It is allowed to change the circuit model
and its parameters while deembedding is enabled.
<Ch>
Channel number.
<Boolean>
ON – Deembedding active
OFF – Deembedding inactive
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
CALC:TRAN:VNET:GLO:DEEM:TND SL
Select the Shunt L circuit model for deembedding.
CALC:TRAN:VNET:GLO:DEEM:PAR:R SL, 2.2E+3; :CALC:TRAN:VNET:GLO:DEEM ON
Increase the resistance for the Shunt L circuit model to 2.2 kΩ and enable
deembedding.
