CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:PARameter
s:C<no> STSC | SCST | CSSL | LSSC | CSSC | SLCS | SCLS |
SCCS,<numeric_value>
Specifies the capacitance values C1, C2, C3 in the different circuit models for port pair embedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>
:DEFine
<no>
Number of capacitance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of capacitances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Capacitance C<no> for the specified circuit model.
Range [def. unit]
–1mF to 1 mF [F]. The increment is 1 fF (10
–15
F).
*RST value
1 pF (10
–12
F)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the capacitance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:PPA:EMB:DEF 1,2; :CALC:TRAN:VNET:PPA:EMB:PAR:C2?
CSSL
Query the default capacitance C2 for the Serial Cs, shunt L circuit model. The
response is 1E-012 (1 pF).
CALC:TRAN:VNET:PPA:EMB:PAR:C2 CSSL, 2.2E-12
Increase the capacitance to 2.2 pF.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:PARameter
s:L<no> STSL | SLST | CSSL | LSSC | LSSL | SLCS | SCLS |
SLLS,<numeric_value>
Specifies the inductance values L1, L2, L3 in the different circuit models for port pair embedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>
:DEFine
<no>
Number of inductance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of inductances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
