SCPI Command Reference
Operating Manual 1145.1084.12 – 30 714
<numeric_value>
Inductance L<no> for the specified circuit model.
Range [def. unit]
–1H to 1 H [H]. The increment is 1 pH (10
–12
H).
*RST value
1 nH (10
–9
H)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the inductance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:PPA:EMB:DEF 1,2; :CALC:TRAN:VNET:PPA:EMB:PAR:L1?
CSSL
Query the default inductance L1 for the Serial Cs, shunt L circuit model. The
response is 1E-009 (1 nH).
CALC:TRAN:VNET:PPA:EMB:PAR:L1 CSSL, 2.2E-9
Increase the inductance to 2.2 nH.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:PARameter
s:R<no> STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS | SCLS |
SCCS | SLLS,<numeric_value>
Specifies the resistance values R1, R2, R3 in the different circuit models for port pair embedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>
:DEFine
<no>
Number of resistance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of resistances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Resistance R<no> for the specified circuit model.
Range [def. unit]
–10 MΩ to 10 MΩ [Ω]. The increment is 1 mΩ (10
–3
Ω).
*RST value
0 Ω for all resistances connected in series with an inductance
10 MΩ for all resistances connected in parallel with a capacitance
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the resistance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:PPA:EMB:DEF 1,2
CALC:TRAN:VNET:PPA:EMB:PAR:R1? CSSL; R2? CSSL; R3? CSSL
Query the default resistances for the Serial Cs, shunt L circuit model. The
response is 10000000000;10000000000; 0.
CALC:TRAN:VNET:PPA:EMB:PAR:R3 CSSL, 2.2E+3
Increase the resistance R3 to 2.2 kΩ.
