R&S ZVB - Page 730

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 715
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>[:STATe]
<Boolean>
Enables or disables the embedding function for port pairs. It is allowed to change the circuit model and its
parameters while embedding is enabled.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:DEFi
ne
<Boolean>
ON – Embedding active
OFF – Embedding inactive
*RST value
OFF [–]
SCPI,
Command
Types
Device-specific, command or query
Example:
*RST; :CALC:TRAN:VNET:PPA:EMB:DEF 1,2,3,4
Define a port pair configuration with two port pairs.
CALC:TRAN:VNET:PPA:EMB1:TND CSSL
Select the Serial Cs, shunt L circuit model for port pair no. 1.
CALC:TRAN:VNET:PPA:EMB:PAR:R3 CSSL, 2.2E+3; :CALC:TRAN:VNET:PPA:EMB ON
Increase the resistance R3 for the Serial Cs, shunt L circuit model to 2.2 kΩ and enable
embedding.
...
CALC:TRAN:VNET:PPA:EMB:DEL
Delete the port pair configuration.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:TNDefinitio
n FIMPort | STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS |
SCLS | SCCS | SLLS
Selects the circuit model for port pair embedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<List_idx>:DEFi
ne
Parameters
Possible circuit models (character data); see circuit models.
*RST value
CSSL
SCPI,
Command
Types
Device-specific, command or query.
Example:
See CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding[:STATe]
