R&S ZVB - Page 785

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 770
Example:
MMEM:LOAD:CKIT 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\Kits\New_kit.calkit'
Load the previously created cal kit file New_kit.calkit from
the default cal kit directory.
... :MMEM:STOR:CKIT 'New_kit', 'C:\Program
Files\Rohde&Schwarz\Network
Analyzer\Calibration\Kits\New_kit.calkit'
Store the data for the user-defined cal kit Newkit and
overwrite the cal kit file New_kit.calkit.
MMEMory:LOAD:CKIT:SDATa '<conn_name>', '<ckit_name>', MMTHrough |
MFTHrough | FFTHrough | MMLine | MMLINE1 | MMLINE2 | MMLINE3 | MFLine |
MFLINE1 | MFLINE2 | MFLINE3 | FFLine | FFLINE1 | FFLINE2 | FFLINE3 | MMATten |
MFATten | FFATten | MMSNetwork | MFSNetwork | FFSNetwork | MOPen | FOPen |
MSHort | FSHort | MOSHort | MOSHORT1 | MOSHORT2 | MOSHORT3 | FOSHort |
FOSHORT1 | FOSHORT2 | FOSHORT3 | MREFlect | FREFlect | MMTCh | FMTCh |
MSMatch | FSMatch, '<stdlabel_name>', '<file_name>' [,<port1_no>][,<port2_no>]
Loads cal kit data for a specific connector type, cal kit, and calibration standard from a specified
Touchstone file, assigning a label for the cal data. A restriction on the port assignment may be defined in
addition.
Renormalization rules
In automatic renormalization mode (MMEMory:SETTings:RENorm:MODE AUTO), renormalization is
enabled. In explicit renormalization mode (MMEMory:SETTings:RENorm:MODE EXPLicit),
renormalization is controlled by MMEMory:SETTings:RENorm:STATe.
The analyzer uses the line impedance of the connector type as a target impedance; the
MMEMory:SETTings:RENorm:RIMPedance setting is ignored.
'<conn_name>'
String parameters containing the name of the connector type.
'<ckit_name>'
String parameters containing the name of a calibration kit available on the
analyzer.
Parameters
Standard type; for a description refer to the table of standard types.
'<stdlabel_name>'
String parameter defining a label for the cal kit data. An empty string means
that no label is defined.
'<file_name>'
String parameter to specify the name and directory of the Touchstone file to be
loaded. A *.s1p file must be used for one-port standards, a *.s2p file for two-
port standards. If no path is specified the analyzer searches the current
directory, to be queried with MMEMory:CDIRectory?.
<port1_no>,
<port2_no>
Port assignment: One port number for one-port standards, two port number for
two-port standards. If the port numbers are omitted, the cal kit data is valid for
all ports.
*RST value
–
SCPI, Command
Types
Device-specific, no query.
