ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 784
SCPI,
Command
Types
Device-specific, no query.
Example:
CALC:TRAN:VNET:GLO:DEEM:TND FIMP
Select the 1-Port Data (s1p) circuit model.
MMEM:LOAD:VNET:GLO:DEEM2 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\VNET\Test.s1p'
Load a Touchstone file.
MMEMory:LOAD:VNETworks<Ch>:GLOop:EMBedding '<file_name>'
Loads data from a specified one-port (*.s1p) Touchstone file defining a ground loop circuit model for
embedding. Select the ground loop circuit model involving file import (FIMPort) before using the
command.
<Ch>
Channel number.
'<file_name>'
String parameter to specify the name and directory of the loaded Touchstone file.
If no path is specified the analyzer searches the current directory, to be queried
with MMEMory:CDIRectory?.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
CALC:TRAN:VNET:SEND:GLO:TND FIMP
Select the 1-Port Data (s1p) circuit model.
MMEM:LOAD:VNET:GLO:EMB 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\VNET\Test.s1p'
Load a Touchstone file.
MMEMory:LOAD:VNETworks<Ch>:PPAir:DEEMbedding<List_idx> '<file_name>',
PMAin | PSECondary[, IPORts]
Loads data from a specified Touchstone file defining a port pair circuit model for deembedding. Select a
port pair with a circuit model involving file import before using the command.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>:
DEFine
'<file_name>'
String parameter to specify the name and directory of the loaded Touchstone file.
The port pair circuit models STSL | STSC | SLST | SCST require two 2-port
(*.s2p) files, to be assigned to the different ports PMAin and PSECondary; the
FIMPort model requires a single 4-port (*.s4p) file but no additional port
