SOURce<Ch>:POWer<Pt>:CORRection:IMODulation:RPORt[:ACQuire].
<Ch>
Channel number
<port_no>
Port number. This suffix is ignored; the analyzer calibrates the port that is selected as
receive port for the intermodulation measurement
([SENSe<Ch>:]FREQuency:IMODulation:RECeiver).
SCPI,
Command
Types
Device-specific, no query
Example:
See SOURce<Ch>:POWer<port_no>:CORRection:IMODulation:LTONe[:ACQuire].
[SENSe<Ch>:]CORRection:POWer<port_no>:IMODulation:RPORt:ACQuire
Starts the receiver calibration (2nd power calibration step for intermodulation measurements), stores and
applies the calibration data.
The receiver calibration relies on the source power calibration acquired in step no. 1
(SOURce<Ch>:POWer<port_no>:CORRection:IMODulation:SPORts[:ACQuire]). Make sure to
first perform step no. 1 before performing this step.
This calibration encompasses the lower and upper tone frequency range as well as the frequency range
for all lower and upper intermodulation products which have been selected via
[SENSe<Ch>:]FREQuency:IMODulation:ORDer<Im>:STATe. If in addition to the intermodulation
measurement a mixer measurement is set up as well, only the IF frequency ranges will be measured.
<Ch>
Channel number
<port_no>
Port number. This suffix is ignored; the analyzer calibrates the port that is selected as
receive port of the intermodulation measurement
([SENSe<Ch>:]FREQuency:IMODulation:RECeiver).
SCPI,
Command
Types
Device-specific, no query
Example:
See SOURce<Ch>:POWer<Pt>:CORRection:IMODulation:SPORts[:ACQuire]
[SENSe<Ch>:]CORRection:POWer<port_no>:MIXer:IF:ACQuire
Starts the IF receiver calibration (2nd power calibration step for scalar mixer measurements), stores and
applies the calibration data.
The receiver calibration relies on the RF source power calibration acquired in step no. 1.
[SENSe<Ch>:]CORRection:POWer<port_no>:MIXer:IF:ACQuire is enabled only after step 1 has
been carried out (SOURce<Ch>:POWer<Pt>:CORRection:MIXer:RF[:ACQuire]).
<Ch>
Calibrated channel number
<port_no>
Calibrated port number. This suffix is ignored; the port is selected via
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:IFPort.
SCPI,
Device-specific, no query
