R&S ZVB - Page 923

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 908
Select 5 as the maximum IM order for the intermodulation spectrum
measurement.
SENS2:FREQ:IMOD:SPEC ON
Enable the intermodulation spectrum measurement for the new channel no. 2.
[SENSe<Ch>:]FREQuency:IMODulation:TDIStance <tone distance>
Defines the tone distance (frequency offset) between the upper and the lower tone.
<Ch>
Channel number.
<tone
distance>
Upper tone frequency minus lower tone frequency.
Range [def.
unit]
Lower limit: 0 Hz, upper limit depending on the instrument model and the sweep
range for the lower tone [Hz]. The increment (parameters UP or DOWN) is 1 kHz.
*RST value
1 MHz
SCPI,
Command
Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:IMODulation:LTONe
[SENSe<Ch>:]FREQuency:IMODulation:TTOutput PORT | EDEVice
Selects the source for the two tone output signal for intermodulation measurements.
<Ch>
Channel number.
Parameters
Two tone output:
PORT – analyzer port 1 (for instruments with option R&S ZVA<frequency>-B16
or with internal combiner only)
EDEVice – external device (Ext. Dev.)
*RST value
EDEVice
SCPI, Command
Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:IMODulation:LTONe
[SENSe<Ch>:]FREQuency:IMODulation:UTONe PORT | GENerator, <source_no>
Selects the source for the upper tone signal that is used for the intermodulation measurement.
<Ch>
Channel number.
Parameters
Upper tone source:
PORT – internal source at port <source_no>
GENerator – external generator no. <source_no>, as defined in the System
