R&S ZVB - Page 924

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 909
Configuration – External Generators dialog.
<source_no>
Number of the port for the internal source or of the generator
Range [def. unit]
1 to port number of the analyzer/number of external generators [–]
*RST value
– (for all parameters)
SCPI, Command
Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:IMODulation:LTONe
[SENSe<Ch>:]FREQuency:MDELay...
This subsystem controls the analyzer's mixer delay measurement mode. This mode requires options R&S
ZVA-K9 and R&S ZVA-K4. Option R&S ZVA-K4 also provides Harmonic Distortion measurements, mixer
measurements, arbitrary configuration of generator and receiver frequencies (Port Configuration), and
intermodulation measurements.
[SENSe<Ch>:]FREQuency:MDELay:ACQuire
Starts a calibration sweep for the mixer delay measurement. As a prerequisite, the calibrated channel
must have at least one mixer delay trace.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
SCPI, Command Types
Device-specific, no query.
Example:
See MMEMory:LOAD:MDCData
[SENSe<Ch>:]FREQuency:MDELay:APERture <Aperture>
Defines the frequency difference between the upper and lower tone (aperture).
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Aperture>
Aperture
Range [def. unit]
0 Hz to 15 MHz [Hz]
*RST value
0 Hz
SCPI, Command
Types
Device-specific, command or query.
Example:
*RST; SENS1:FREQ:STAR 1 GHz; STOP 2 GHz
Select a stimulus range between 1 GHz and 2 GHz.
FREQ:MDEL:APER 1 MHz
Select a 1 MHz aperture.
FREQ:MDEL:UTON PORT, 3
Select NWA port 3 as a source port for the upper tone (no external generator).
FREQ:MDEL:COMB ON
Use the internal combiner to generate the two-tone signal at port 1 (for
